Allen-Bradley PowerFlex 70 Reference Manual

2-214 Watts Loss
(2)
Worst case condition including Vector Control board, HIM and Communication Module
480V 0.5 11 42 53
119 44 63
231 45 76
346 46 93
578 87 164
7.5 115 79 194
10 134 84 218
15 226 99 326
20 303 91 394
25 339 102 441
30 357 103 459
40 492 117 610
50 568 148 717
60 722 207 930
75 821 286 1107
100 1130 397 1479
125 1402 443 1845
150 1711 493 2204
200 1930 583 2512
600V 0.5 9 37 46
114 40 54
225 40 65
341 42 83
559 83 142
7.5 83 75 157
10 109 77 186
15 177 93 270
20 260 83 343
25 291 95 385
30 324 95 419
40 459 109 569
50 569 141 710
60 630 195 825
75 1053 308 1361
100 1467 407 1874
125 1400 500 1900
150 1668 612 2280
Voltage ND HP External Watts Internal Watts Total Watts Loss

Allen-Bradley PowerFlex 70 Specifications

General

Input Voltage	200-240V AC, 380-480V AC, 500-600V AC
Frequency Range	0 - 400 Hz
Humidity	5% to 95% non-condensing
Output Voltage	0 to Input Voltage
Control Methods	Sensorless Vector Control
Communications	Ethernet/IP, DeviceNet, ControlNet
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Ground Fault
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Enclosure Rating	IP20, NEMA Type 1
