Allen-Bradley PowerFlex 70 Reference Manual

Determining Dynamic Brake Requirements 2-3
Figure 2.1 Application Speed, Torque and Power Profiles
0
t
1
t
2
t
3
t
4
t
1
+ t
4
t
0
t
1
t
2
t
3
t
4
t
1
+ t
4
t
0
t
1
t
2
t
3
t
4
t
1
+ t
4
t
ω (t)
T(t)
P(t)
0
t
1
t
2
t
3
t
4
t
1
+ t
4
t
-P
b
P
rg
ω
o
ω
b
Speed
Torque
Power
Drive Rated
Regen Power

Allen-Bradley PowerFlex 70 Specifications

General

Input Voltage	200-240V AC, 380-480V AC, 500-600V AC
Frequency Range	0 - 400 Hz
Humidity	5% to 95% non-condensing
Output Voltage	0 to Input Voltage
Control Methods	Sensorless Vector Control
Communications	Ethernet/IP, DeviceNet, ControlNet
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Ground Fault
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Enclosure Rating	IP20, NEMA Type 1
