Allen-Bradley PowerFlex 70 Reference Manual

PowerFlex 700 Dimensions 1-19
5
75 HP,
480V
(55kW,
400V)
Normal
Duty
Drive
100 HP,
480V
Normal
Duty
Drive
6
All
Frame Rating Dimensions in millimeters and (inches)
96.0
(3.78)
159.5
(6.28)
184.0
(7.24)
220.0
(8.66)
229.5
(9.04)
241.9
(9.52)
45.0 (1.77)
85.0 (3.35)
93.2 (3.67)
104.0 (4.09)
150.0 (5.91)
215.0 (8.46)
255.0 (10.04)
28.0 (1.10)
22.2 (0.87) Dia.
2 Places
62.7 (2.47) Dia.
2 Places
34.9 (1.37) Dia.
2 Places
96.0
(3.78)
153.5
(6.04)
184.3
(7.26)
188.5
(7.42)
223.5
(8.80)
241.9
(9.52)
44.0 (1.73)
66.4 (2.61)
31.9 (1.26)
42.6 (1.68)
128.0 (5.04)
232.3 (9.15)
28.0 (1.10)
22.2 (0.87) Dia.
2 Places
62.7 (2.47) Dia.
2 Places
Removable Junction Box
34.9 (1.37) Dia.
116.6
(4.59)
148.5
(5.85)
222.3
(8.75)
242.0
(9.53)
219.0
(8.62)
185.4
(7.30)
151.8
(5.98)
52.1 (2.05)
69.1 (2.72)
130.1 (5.12)
280.1 (11.03)
330.1 (13.00)
230.1 (9.06)
47.1 (1.85)
45.6 (1.80)
56.2 (2.21)
Removable Junction Box
22.2 (0.87) Dia.
4 Places
62.7 (2.47) Dia.
3 Places
34.9 (1.37) Dia.
3 Places

Allen-Bradley PowerFlex 70 Specifications

General

Input Voltage	200-240V AC, 380-480V AC, 500-600V AC
Frequency Range	0 - 400 Hz
Humidity	5% to 95% non-condensing
Output Voltage	0 to Input Voltage
Control Methods	Sensorless Vector Control
Communications	Ethernet/IP, DeviceNet, ControlNet
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Ground Fault
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Enclosure Rating	IP20, NEMA Type 1
