Allen-Bradley PowerFlex 70 Reference Manual

Selecting An External Resistor 4-5
Table 4.A Resistor Selection – 240V AC Drives
Ohms Watts
Watt
Seconds
Catalog
Number
154 913 16431 220-1
154 610 16431 220-1A
154 604 16431 225-1
154 408 6416 225-1A
154 242 6416 222-1
154 182 6416 222-1A
117 3000 20800 T117R3K0
117 2700 14300 T117R2K7
117 2100 18600 T117R2K1
117 1500 15800 T117R1K5
117 1200 12500 T117R1K2
117 900 10600 T117R900W
117 600 10100 T117R600W
117 300 7950 T117R300W
110 1278 46947 220-2
110 850 18779 220-2A
110 845 18779 225-2
110 570 18779 225-2A
110 338 7511 222-2
110 255 7511 222-2A
97 4200 19100 T97R4K2
97 3600 22400 T97R3K6
97 3000 16800 T97R3K0
97 2700 19100 T97R2K7
97 2100 15400 T97R2K1
97 1500 20800 T97R1K5
97 1200 16500 T97R1K2
97 900 13800 T97R900W
97 600 13400 T97R600W
97 300 10300 T97R300W
91 86 17000 AKR2091P500
85 1654 57901 220-3
85 1094 36384 225-3
85 1089 36384 220-3A
85 730 23004 225-3A
85 438 9076 222-3
85 326 9076 222-3A
80 9300 230000 T80R9K3
80 9000 209000 T80R9K0
80 5700 29400 T80R5K7
80 4500 23300 T80R4K5
80 4200 25100 T80R4K2
80 3600 18500 T80R3K6
80 3000 22100 T80R3K0
80 2700 24600 T80R2K7
80 2100 19100 T80R2K1
80 1500 17500 T80R1K5
80 1200 13700 T80R1K2
80 900 18500 T80R900W
80 600 10900 T80R600W
80 300 8530 T80R300W
77 9300 230000 T77R9K3
77 9000 209000 T77R9K0
77 5700 28700 T77R5K7
77 4500 22400 T77R4K5
77 4200 24200 T77R4K2
77 3600 28100 T77R3K6
77 3000 21300 T77R3K0
77 2700 23800 T77R2K7
77 2100 19100 T77R2K1
77 1500 16400 T77R1K5
77 1200 20800 T77R1K2
77 900 17900 T77R900W
77 600 10600 T77R600W
77 300 8210 T77R300W
60 11000 448000 T60R11K0
60 6900 164000 T60R6K9
60 4500 28000 T60R4K5
60 3600 22000 T60R3K6
60 2700 18500 T60R2K7
60 1500 20800 T60R1K5
60 1200 16400 T60R1K2
60 900 13700 T60R900W
60 600 13000 T60R600W
60 300 10300 T60R300W
59 2384 99762 220-4
59 1577 64161 220-4A
59 1576 64161 225-4
59 1056 39201 225-4A
59 631 25038 222-4
59 473 10094 222-4A
48 20400 716000 T48R20K4
48 19100 656000 T48R19K1
48 12600 359000 T48R12K6
48 6600 131000 T48R6K6
48 5670 131000 T48R5K67
48 4200 23800 T48R4K2
48 3600 28000 T48R3K6
48 3000 21100 T48R3K0
Ohms Watts
Watt
Seconds
Catalog
Number

Allen-Bradley PowerFlex 70 Specifications

General

Input Voltage	200-240V AC, 380-480V AC, 500-600V AC
Frequency Range	0 - 400 Hz
Humidity	5% to 95% non-condensing
Output Voltage	0 to Input Voltage
Control Methods	Sensorless Vector Control
Communications	Ethernet/IP, DeviceNet, ControlNet
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Ground Fault
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Enclosure Rating	IP20, NEMA Type 1
