PowerFlex 700 Technical Data
54 20B-TD001F-EN-P
Frame 5 NEMA/UL Type 12 Flange Mount – 400…690V Only
Dimensions are in millimeters and (inches)
Frame
Description
Approx. Weight
(1)
kg (lbs.)
(1)
Weights include HIM and Standard I/O.
Drive Drive & Packaging
5 Flange Mount 61.69 (136.0) 81.65 (180.0)
303.6
(11.95)
2.3 (0.09)
Compressed
Gasket
97.0
(3.82)
384.0
(15.12)
42.0
(1.65)
1061.0
(41.77)
1039.0
(40.91)
11.0
(0.43)
500.0
(19.69)
478.0
(18.82)
5.5 (0.22) Dia. Holes for
Supplied Mounting Hardware
40 Plcs.
12.7 (0.50) Dia. Lifting Holes - 4 Plcs.
Air
Outlet
11.0
(0.43)
53.2
(2.09)
USE 75 C CU WIRE ONLY
WIRE RANGE: 4-3/0 AWG (18-70 MM
2
)
TORQUE: 133 IN-LB (15 N-M)
STRIP LENGTH: 1.02 IN (26 MM)
POWER & DC TERMINAL RATINGS
WIRE RANGE: 14-1/0 AWG (2.5-50 MM
2
)
TORQUE: 32 IN-LB (3.6 N-M)
STRIP LENGTH: 0.67 IN (17 MM)
BRAKE TERMINAL RATINGS
WIRE RANGE: 6-1/0 AWG (18-35 MM
2
)
TORQUE: 44 IN-LB (5 N-M)
STRIP LENGTH: 0.83 IN (21 MM)
GROUND TERMINAL RATINGS (PE)
OUTPUT
INPUT AC
300 VDC EXT PWR SPLY TERM (PS+, PS-)
WIRE RANGE: 22-10 AWG (0.5-4 MM
2
)
TORQUE: 5.3 IN-LB (0.6 N-M)
STRIP LENGTH: 0.35 IN (9 MM)
DANGER
DANGER
RISK OF ELECTRIC
SHOCK AND DEATH
FIELD INSTALLED OPTIONS
6 MM HEX KEY6 MM HEX KEY
SHLD
SHLD
219.5
(8.64)
196.5
(7.74)
185.0
(7.30)
449.6
(17.74)
127.6
(5.02)
194.0
(7.60)
Ground
M5 PEM Nut
To Next Page
