40 Rockwell Automation Publication 750-UM003D-EN-P - March 2017
Chapter 4 ATEX Monitoring
ATEX Fault Descriptions
Table 3 contains a list of ATEX-specific faults, a description, and the corrective
action (where applicable).
Table 3 - ATEX Faults, Descriptions, and Actions
ATEX Configuration Errors
Table 4 shows an example of the device conflict text. A conflict can be
enunciated under these conditions:
• During power-up, when the ATEX safety configuration switch is set
improperly.
• If the ATEX option module with the 11-Series I/O option module is
installed in a slot other than 4 or 5.
Table 4 - ATEX Configuration Errors
Event
No.
(1)
(1) xx indicates the port number where the ATEX option module is installed.
Fault/Alarm Text Type Fault
Action
(2)
(2) These faults initiate the ATEX function (uncontrolled stop).
Description/Corrective Action
xx011 PTC Over Temp
Resettable
fault
Coast
An over-temperature condition has been
detected in the motor, or the sensor path has
been broken.
xx012 PTC ShortCircuit
A short circuit condition has been detected in the
sensor path. If the fault is unable to be cleared,
make sure the thermal sensor that is connected
is a PTC-type and not thermostatic.
xx013 ATX VoltageLoss
Possible hardware damage.
A short in the motor to the thermal sensor.
An excess of electromagnetic compatibility
(EMC) noise due to improper grounding/
shielding.
xx014 ThermostatOvrTmp
An over-temperature condition has been
detected in the motor, or the sensor path has
been broken.
Device Conflict Text Description/Action
X Port 06
The ATEX option module and 11-Series I/O option module is installed in an
unsupported port.
X Port 06 ‘Safe Speed Montr’
The safety configuration switch (S1-1) is set to ‘ON’, and a safety option is
present.
