24 SLC 500 BASIC and BASIC-T Modules
Publication 1746-IN009B-EN-P - August 2005
Specifications
BASIC and BASIC-T Modules Specifications
Specification Value
Power Supply Loading at 5V dc 0.150 A (module only)
0.150 A (module with link coupler)
Power Supply Loading at 24V dc 0.070 A (module only)
0.125 A (module with link coupler)
(2)
(2) If a Hand-Held Terminal, Data Table Access Module, or interface converter is connected to the link coupler, the additional
backplane power draw of these components (listed on page
25) must be added to the 0.125 listed in the table above. This
only applies when the module is connected to the network via the link coupler and 1747-C10 cable or 1747-C11 cable. This
does not apply when the 1747-C13 cable is used.
Noise Immunity NEMA Standard ICS 2-230
Vibration Displacement: 0.015 in, peak-to-peak at 5...57 Hz
Acceleration: 2.5 G at 57...2000 Hz
Shock (operating) 30 G
Port Isolation
(1)
Port PRT1
Port PRT2
Port PRT1 to Port PRT2
(1) Port DH485 is not isolated.
710V dc for 1 minute (backplane to port)
710V dc for 1 minute (backplane to port)
710V dc for 1 minute (port PRT1 to port PRT2)
Ambient Temperature Rating Operating: 0...+60 ° C (+32...+140 °F)
Storage: -40...+85 °C (-40...+185 °F)
Humidity 5...95% without condensation
Clock/Calendar Accuracy ±1 minute/month at 25 °C (77 °F)
+0, -6 minute/month at 60 °C (140 °F)
Certifications
Certification Value
Agency Certification c-UL-us listed
Class I, Groups A, B, C or D, Division 2
CE compliant for all applicable directives
C-Tick marked for all applicable acts
