Allen-Bradley SLC 500 Series Migration Guide

18 Rockwell Automation Publication 1746-RM003D-EN-E - May 2019
Chapter 2 Replace an SLC 500 Controller
Upgrade to a CompactLogix
5380 Controller
See the following table for the recommended replacement CompactLogix 5380
controller to your existing SLC 500 controller. These recommendations exclude
Motion and Safety applications, consult your local sales office for more
information.
For technical specifications of the recommended CompactLogix 5380 controller,
refer to CompactLogix Controllers Specifications Technical Data,
publication 5069-TD002
.
Catalog Number SLC Controller Description Recommended CompactLogix 5380
Controller Replacement
(1)
CompactLogix 5380 Controller Description
1747-L511 SLC 5/01 1K Controller 5069-L306ER CompactLogix 5380 Controller, 600 KB, 8 I/O, 16 nodes, Standard
1747-L514 SLC 5/01 4K Controller 5069-L306ER CompactLogix 5380 Controller, 600 KB, 8 I/O, 16 nodes, Standard
1747-L524 SLC 5/02 4K Controller 5069-L306ER CompactLogix 5380 Controller, 600 KB, 8 I/O, 16 nodes, Standard
1747-L531 SLC 5/03 8K Controller 5069-L306ER CompactLogix 5380 Controller, 600 KB, 8 I/O, 16 nodes, Standard
1747-L532 SLC 5/03 16K Controller 5069-L306ER CompactLogix 5380 Controller, 600 KB, 8 I/O, 16 nodes, Standard
1747-L533 SLC 5/03 32K Controller 5069-L306ER CompactLogix 5380 Controller, 600 KB, 8 I/O, 16 nodes, Standard
1747-L541 SLC 5/04 16K Controller 5069-L306ER CompactLogix 5380 Controller, 600 KB, 8 I/O, 16 nodes, Standard
1747-L542 SLC 5/04 32K Controller 5069-L306ER CompactLogix 5380 Controller, 600 KB, 8 I/O, 16 nodes, Standard
1747-L543 SLC 5/04 64K Controller 5069-L310ER CompactLogix 5380 Controller, 1 MB, 8 I/O, 24 nodes, Standard
1747-L551 SLC 5/05 16K Controller 5069-L306ER CompactLogix 5380 Controller, 600 KB, 8 I/O, 16 nodes, Standard
1747-L552 SLC 5/05 32K Controller 5069-L306ER CompactLogix 5380 Controller, 600 KB, 8 I/O, 16 nodes, Standard
1747-L553 SLC 5/05 64K Controller 5069-L310ER CompactLogix 5380 Controller, 1 MB, 8 I/O, 24 nodes, Standard
(1) The general rule of thumb for memory estimation can be found under “SLC to Logix Memory Comparison” in the SLC/MicroLogix 1500 to CompactLogix Migration Guide, publication 1769-AP001.
Alternatively, you may validate the controller based on memory estimation by the code conversion tool (RSLogix Project Migrator).

Allen-Bradley SLC 500 Series Specifications

General

Programming Software	RSLogix 500
Series	SLC 500
Category	Controller
Manufacturer	Allen-Bradley (Rockwell Automation)
I/O Capacity	Up to 4096 I/O points
Communication Ports	DH-485
Programming Languages	Ladder Logic
Operating Temperature	0 to 60 °C (32 to 140 °F)
Relative Humidity	5% to 95% (non-condensing)
Memory	4K to 64K words (depending on the processor)
Power Supply	AC or DC (depending on the module)
