Allen-Bradley SLC 500

10 SLC 500 Digital I/O Modules
Publication 1746-IN027D-EN-P - December 2012
Location of Jumpers and Fuses for 1746-OAP12 Module
12
3
OUTPUT
1
JP1
23
JP1
F
U
S
E
REPLACEMENT FUSE:
SAN-O HQ 6.3A
A-B CAT. NO. 1746-F9
2
WHEN FUSE OPENS
F1
F2
Jumper for Processor
Notification (JP1)
Left side view
PROCESSOR
CONTINUES
PROCESSOR
FAULT
Jumper Settings and
Fuse Replacement Information
Blown Fuse LED
indicator
Front View
