Location of Jumpers and Fuses for 1746-OBP16 and 1746-OVP16 Modules
F
U
S
E
OUTPUT
WHEN FUSE OPENS
PROCESSOR
CONTINUES
PROCESSOR
FAULTS
REPLACEMENT FUSE
LITTLEFUSE 322010 or 332010
A.B. CAT. NO. 1746-F9
3
2
21
1
2
3
Left side view
Location for 1746-OBP16 Fuse (F1)
Jumper for processor
notification (JP1)
Brown fuse LED
Indicator
Jumper settings and fuse
replacement information
Location for
1746-OVP16
Fuse (F1)
Front view
