allen 6500 - Page 37

ITEM PART # DESCRIPTION QTY
1 010208 Bushing, Reducer, 3/4” x 1/2” 2
2 010243 Pipe, Suction 1
3 010244 Fitting, Elbow, 3/4”, 90°, Female, Galvanizedanized 1
4 010245 Pipe, By-pass 1
5 010246 Fitting, Elbow, 1/2”, 90°, Female Galvanizedanized 1
6 010259 Fitting, Elbow, 3/4”, 90°, Street, Galvanizedanized 1
7 010321 Fitting, Tee, 3/4”, Female, Galvanizedanized 1
8 010508 Fitting, Coupler, Jaw, 5/8” 1
9 010345 Pipe, Nipple, 3/4” x 3”, Galvanizedanized 1
10 010510 Coupler, Jaw, Insert 1
11 012745 Coupler, Jaw, 3/4” 1
12 029411 Hose, By-pass Assembly 1
13 029416 Hose, Spray Wand Assembly 1
14 029418 Pump, Hypro 6500 Series 1
15 029419 Valve, Relief, 3/4” 1
16 029423 Frame, Model 6500 1
17 029427 Bracket, for Pump 1
18 028390 Engine, Honda, 4.0 HP 1
19 029428 Guard, Shaft 1
20 221035 Hose, Suction Assembly 1
21 010241 Lock, Barrel Mount 2
22 010189 Fitting, Coupler, QDC, Female, 1/2” 1
23 040160 Fitting, Nipple, QDC, 1/2”, with male threads 1
FASTENERS
24 024669 Fastener, Bolt, 7/16” x 2” (Barrel Lock) 2
25 010092 Fastener, Lock Washer, 7/16” (Barrel Lock) 2
26
010019 Fastener, Bolt, 5/16” x 3/4” (Shaft Guard) 2
010019 Fastener, Bolt, 5/16” x 3/4” (Pump) 2
27 010036 Fastener, 3/8” x 1” (Pump Mount Bracket) 4
28 010091 Fastener, Lock Washer, 3/8”, (Pump Mount Bracket) 4
29 017751 Fastener, Flat Washerat Washer, 3/8”, Hard (Pump Mount Bracket) 4
30 010022 Fastener, Bolt, 5/16” x 1-1/2” (Engine) 4
31
010082 Fastener, Flat Washerat Washer, 5/16” (Engine) 4
010082 Fastener, Flat Washerat Washer, 5/16” (Shaft Guard) 2
010082 Fastener, Flat Washerat Washer, 5/16” (Pump) 2
32
010090 Fastener, Lock Washer, 5/16” (Engine) 4
010090 Fastener, Lock Washer, 5/16” (Shaft Guard) 2
010090 Fastener, Lock Washer, 5/16” (Pump) 2
4.1 - Model 6500 Assembly, Parts List
SECTION 4
PARTS
038479 Page 37
