4.3 - Model 9910 Assembly, Illustration &
Parts List
ITEM PART # DESCRIPTION QTY
1 010242 Bracket, C-Mod Sy Hose Hanger 2
2 039074 Guard, M990 Sprayer 1
3 038966 Guard, M9910 Sprayer (Top) 1
4 039079 Frame M9910 Sprayer 1
5
033395 Engine, Kawasaki 5.5 Hp 1
018961 Engine, Honda 5.5 Hp 1
6 039073 Guard, M9910 Sprayer (End) 1
7 039071 Locks, Barrel M9910 2
8 010243 Suction Pipe 1
9 010244 Elbow 3/4 90 Deg Female Galvanized 1
10 039072 Bracket, Isolator M9910 Sprayer 1
11 040159 Fitting, Coupler QDC 1/2” W/ Fm Threads 1
SECTION 4
PARTS
038479Page 40
