4.2 - Model 7560 & 7560XL Assembly,
Parts List
Item Part# Description Qty
16 012745 Coupler, Jaw, 3/4” 1
17 011115 Bracket, Motor Mount 2
18 028390 Engine, Honda, 4.0 Hp 1
19 028494-27 Guard, for Frame 2
20 028494-13 Guard, for Frame 1
21 029411 Hose, By-Pass Assembly 1
22
029412 Pump, 7560 Series 1
029432 Pump, 7560XL Series 1
23 029413 Valve, Relief 1
24 029417 Clamp (Not Shown) 1
25 029425 Bracket, Pump 1
26 029428 Guard, Shaft 1
27 029434 Coupler, Jaw, 15/16” 1
28 221065 Hose, Suction Assembly 1
29 010510 Insert, Jaw Coupler 1
30 032192 25’ Hose Assembly Opt
31 032194 100’ Hose Assembly Opt
32 039643 Pump Bracket Spacer 1
33 040160 Fitting, Nipple, QDC, 1/2” with Male Threads 1
(Fastener Parts List)
34 010036 Fastener, 3/8” X 1” (Pump Mount Bracket) 4
35 010091 Fastener, 3/8”, Lock Washer (Pump Mount Bracket) 4
36 017751 Fastener, 3/8”, Hard Flat Washerat Washer (Pump Mount Bracket) 4
37 010026 Fastener, 5/16” X 2-1/2” (Engine) 4
38
010082 Fastener, 5/16”, Flat Washerat Washer (Engine) 4
010082 Fastener, 5/16”, Flat Washerat Washer (Shaft Guard) 2
010082 Fastener, 5/16”, Flat Washerat Washer (2 Frame Guards W/O Hangers) 8
010082 Fastener, 5/16”, Flat Washerat Washer (Pump) 2
39
010090 Fastener, 5/16”, Lock Washer (Engine) 4
010090 Fastener, 5/16”, Lock Washer (Shaft Guard) 2
010090 Fastener, 5/16”, Lock Washer (All Frame Guards) 12
010090 Fastener, 5/16”, Lock Washer (Pump) 2
40 010022 Fastener, 5/16” X 1-1/2” (Pump) 2
41 010023 Fastener, 5/16” X 1-3/4” (All Frame Guards) 12
42
010100 Fastener, 5/16”, Hex Nut (Engine) 4
010100 Fastener, 5/16”, Hex Nut (Shaft Guard) 2
010100 Fastener, 5/16”, Hex Nut (All Frame Guards) 12
43 024669 Fastener, 7/16” X 2” (Barrel Lock) 2
44 010092 Fastener, 7/16”, Lock Washer (Barrel Lock) 2
45 221073 Assembly, Tank Suction Hose (Includes Part #’s 11, 12, 21) 1
46 221074 Assembly, Tank Bypass Hose (Includes Part #’s 9, 10, 28) 1
SECTION 4
PARTS
038479 Page 39
