4.6 - Model 6500 Pump Assembly,
Parts List
ITEM PART # DESCRIPTION QTY
1 2300-0021 Bearing Cover 1
2 2000-0010 Sealed Ball Bearing 2
3* 2107-0002 Viton Seal (Reference to kit below, sold as kit ONLY, can not be parted) 2
4 2210-0004 Fastener, Bolt for End Plate 4
5
0200-6600C End Plate (Cast Iron) 1
0200-6600N End Plate (Ni-Resist) 1
0200-6600X End Plate (Silver Cast) 1
6* 1720-0008 O-ring, for end plate (Reference to kit below, sold as kit ONLY, can not be parted) 1
7*
1720-0104 Super Roller (Reference to kit below, sold as kit ONLY, can not be parted) 6
1002-0004 Polypropylene Roller (Optional) 6
1055-0004 Teon Roller (Optional) 6
8 3420-0023
Base Kit - Sold Separately
Includes: (1) Base, (2) Bolts, and (2) Washers
-
9
0100-6600C Body (Cast Iron) 1
0100-6600N Body (Ni-Resist) 1
0100-6600X Body (Silver Cast) 1
10 2300-0023 Cover, Shaft Bearing 1
11
0300-6600C Rotor Assembly (Cast Iron) 1
3430-0767 Rotor Assembly (std. Ni-Resist & XL) 1
REPAIR KIT
ITEM PART # DESCRIPTION (Parts sold as kit ONLY, can not be parted) QTY
- 3430-0343
Kit, Repair, Universal, for 6500/7560 Pump
Consists of:
• 2107-0002, (Vition Seal) x 2
• 2122-0003, (Vition Seal) x 2
• 1720-0008 (O-ring) x 1
• 1720-0014 (O-ring) x 1
• 1720-0104 (Super Roller) x 8
1
