allen 6500 - Page 49

ITEM PART # DESCRIPTION QTY
1 2300-0021 Bearing Cover 1
2 2000-0010 Sealed Ball Bearing 2
3* 2112-0003 Viton Seal (Reference to kit below, sold as kit ONLY, can not be parted) 2
4 2210-0004 Fastener, Bolt for End Plate 6
5
0204-7500C End Plate (Cast Iron) 1
0204-7500N End Plate (Ni-Resist) 1
204-7500X End Plate (Silver Cast) 1
6* 1720-0014 O-ring, for end plate (Reference to kit below, sold as kit ONLY, can not be parted) 1
7*
1720-0104 Super Roller (Reference to kit below, sold as kit ONLY, can not be parted) 8
1002-0004 Polypropylene Roller (Optional) 8
1055-0004 Teon Roller (Optional) 8
8
0308-7560C Rotar Assembly (Cast Iron) 1
3430-0745 Rotor Assembly (Std. Ni-Resist & XL) 1
10 3420-0023
Base Kit - Sold Separately
Includes: (1) Base, (2) Bolts, and (2) Washers
-
11
0104-7500C Body (Cast Iron) 1
0104-7500N Body (Ni-Resist) 1
0104-7500X Body (Silver Cast) 1
12 2300-0022 Cover, Shaft Bearing 1
13
1610-0005 Key 1
1610-0059 Key (Stainless Steel) 1
REPAIR KIT
ITEM PART # DESCRIPTION (Parts sold as kit ONLY, can not be parted) QTY
- 3430-0343
Kit, Repair, Universal, for 6500/7560 Pump
Consists of:
• 2107-0002, (Vition Seal) x 2
• 2122-0003, (Vition Seal) x 2
• 1720-0008 (O-ring) x 1
• 1720-0014 (O-ring) x 1
• 1720-0104 (Super Roller) x 8
1
4.7 - Model 7560 Pump Assembly,
Parts List
SECTION 4
PARTS
038479 Page 49
