ITEM PART # DESCRIPTION QTY
1
029420 Spray Tip, Large [Standard] (5.5 GPM) 1
012703 Spray Tip, Medium (Mist) {8003} [Optional] (0.82 GPM) -
012702 Spray Tip, Fine (Fogger) {8001} [Optional] (0.27 GPM) -
2 029415 Spray Gun (INCLUDES ONE (1) 029420 SPRAY TIP) 1
3 010177 Fitting, Nipple, QDC, 1/2”, Male (7560 & 9910) 2
4 010189 Fitting, Coupler, QDC, 1/2”, Female (7560 & 9910) 1
5 9920-164.604.14 Fitting, 3/8” Hose Connector With 1/2” Nut (6500 &7560) 1
6 029417 Clamp, 01518 (6500 &7560) 1
7 013392 Hose, Push-lock, 3/8”, 25’ (6500 & 7560) 1
8 013392 Hose, Push-lock, 3/8”, 100’ (6500 & 7560) 1
9 010196 Fitting, Push-Lock, Male, 3/8” x 1/2”-14 (6500 & 7560) 1
10 010336 Coupler, 1/2” Pipe (9910 ONLY) 1
11 013057 Swage, 11355-8-6 Perm. (9910 ONLY) 2
12 028939 Hose, Aeroquip, H-I 25’ (9910 ONLY) 25
13 028939 Hose, Aeroquip, H-I, 100’ (9910 ONLY) 100
14 019430 Fastener, Clamp, #4 Mini Hose (6500 & 7560) 1
15 032650 Nut, Brass Ring, Spray Gun (NOT CALLED OUT) 1
4.12 - Spray Wand Assembly, Parts List
HOSE ASSEMBLIES
ITEM PART # DESCRIPTION QTY
1 029436 Hose Assembly, 50’ with Fittings (7560 ONLY) 1
2 032194 Hose Assembly, 100’ with Fittings (7560 ONLY) 1
3 047338 Hose Assembly 50’ W/ Fittings (9910 ONLY) 1
4 047339 Hose Assembly 100’ W/ Fittings (9910 ONLY) 1
5 029411 Hose Assembly, Bypass, 72” (1/2 Hose) 1
6 221065 Hose Assembly, Suction, 60” 1
SECTION 4
PARTS
038479 Page 57
