Specifications and Dimensions
D1343
10
Table 1
Machine Capacity lb. (l)
12 (60) 14 (65) 18 (75) 25 (100)
A
1054 mm (41.5 in.) 1054 mm (41.5 in.) 1054 mm (41.5 in.) 1054 mm (41.5 in.)
B
1024 mm (40.3 in.) 1024 mm (40.3 in.) 1024 mm (40.3 in.) 1024 mm (40.3 in.)
C
275 mm (10.8 in.) 275 mm (10.8 in.) 275 mm (10.8 in.) 275 mm (10.8 in.)
D
33 mm (1.3 in.) 33 mm (1.3 in.) 33 mm (1.3 in.) 33 mm (1.3 in.)
E
65 mm (2.6 in.) 65 mm (2.6 in.) 65 mm (2.6 in.) 65 mm (2.6 in.)
F
530 mm (20.9 in.) 530 mm (20.9 in.) 530 mm (20.9 in.) 530 mm (20.9 in.)
G
660 mm (26.0 in.) 660 mm (26.0 in.) 660 mm (26.0 in.) 660 mm (26.0 in.)
H
33 mm (1.3 in.) 33 mm (1.3 in.) 33 mm (1.3 in.) 33 mm (1.3 in.)
I
65 mm (2.6 in.) 65 mm (2.6 in.) 65 mm (2.6 in.) 65 mm (2.6 in.)
J
921 mm (36.3 in.) 921 mm (36.3 in.) 921 mm (36.3 in.) 921 mm (36.3 in.)
K
801 mm (31.6 in.) 801 mm (31.6 in.) 801 mm (31.6 in.) 801 mm (31.6 in.)
L
736 mm (29.0 in.) 736 mm (29.0 in.) 736 mm (29.0 in.) 736 mm (29.0 in.)
M
490 mm (19.3 in.) 490 mm (19.3 in.) 490 mm (19.3 in.) 490 mm (19.3 in.)
N
660 mm (26.0 in.) 660 mm (26.0 in.) 660 mm (26.0 in.) 660 mm (26.0 in.)
O
180 mm (7.1 in.) 180 mm (7.1 in.) 180 mm (7.1 in.) 180 mm (7.1 in.)
P
47.5 mm (1.9 in.) 47.5 mm (1.9 in.) 47.5 mm (1.9 in.) 47.5 mm (1.9 in.)
Q
698 mm (27.5 in.) 698 mm (27.5 in.) 698 mm (27.5 in.) 698 mm (27.5 in.)
R
209 mm (8.2 in.) 209 mm (8.2 in.) 209 mm (8.2 in.) 209 mm (8.2 in.)
S
226 mm (8.9 in.) 226 mm (8.9 in.) 226 mm (8.9 in.) 226 mm (8.9 in.)
T
291 mm (11.5 in.) 291 mm (11.5 in.) 291 mm (11.5 in.) 291 mm (11.5 in.)
U
311 mm (12.2 in.) 311 mm (12.2 in.) 311 mm (12.2 in.) 311 mm (12.2 in.)
V
51.5 mm (2.0 in.) 51.5 mm (2.0 in.) 51.5 mm (2.0 in.) 51.5 mm (2.0 in.)
W
30 mm (1.2 in.) 30 mm (1.2 in.) 30 mm (1.2 in.) 30 mm (1.2 in.)
X
590 mm (23.2 in.) 590 mm (23.2 in.) 590 mm (23.2 in.) 690 mm (27.2 in.)
Y
650 mm (25.6 in.) 650 mm (25.6 in.) 650 mm (25.6 in.) 750 mm (29.5 in.)
Z
711 mm (28.0 in.) 711 mm (28.0 in.) 711 mm (28.0 in.) 811 mm (31.9 in.)
AA
30.6 mm (1.2 in.) 30.6 mm (1.2 in.) 30.6 mm (1.2 in.) 30.6 mm (1.2 in.)
AB
92.9 mm (3.7 in.) 92.9 mm (3.7 in.) 92.9 mm (3.7 in.) 92.9 mm (3.7 in.)
