Gas Requirements
Part No. 70458301ENR7
©
Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT 67
Altitude Burner Orifice New Rate
Model Gas feet (meters) No.
inches
( mm) Quantity Part No.
Btu/hr.*
(Mj/hr.)
6,001-8,000
( 1,831-2,440)
43 0.0890 (2.3) M406184 55,480
(58.53)
8,001-10,000
( 2,441-3,050)
44 0.0860 (2.2) M401011 49,640
(52.37)
2,001-4,000
( 610-1,220)
22 0.1570 (4.0) M402996 134,320
(141.71)
4,001-6,000
( 1,221-1,830)
24 0.1520 (3.9) M402980 122,640
(129.39)
6,001-8,000
( 1,831-2,440)
26 0.1470 (3.7) M401000 110,960
(117.06)
Natural
Gas
8,001-10,000
( 2441-3,050)
28 0.1405 (3.6) M401014 99,280
(104.74)
2,001-6,000
( 610-1,830)
42 0.0935 (2.4) M403017 134,320
(141.71)
6,001-8,000
( 1,831-2,440)
43 0.0890 (2.3) M406184 110,960
(117.06)
T30 Series
L.P. Gas
8,001-10,000
( 2,441-3,050)
44 0.0860 (2.2)
2
M401011 99,280
(104.74)
2,001-4,000
( 610-1,220)
17 0.1730 (4.4) M411374 82,800
(87.35)
4,001-6,000
( 1,221-1,830)
18 0.1695 (4.3) M402988 75,600
(79.76)
6,001-8,000
( 1,831-2,440)
20 0.1610 (4.1) M401002 68,400
(72.16)
035 Series Natural
Gas
8,001-10,000
( 2,441-3,050)
22 0.1570 (4.0)
1
M402996 61,200
(64.57)
