Gas Requirements
Part No. 70458301ENR7
©
Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT 69
Altitude Burner Orifice New Rate
Model Gas feet (meters) No.
inches
( mm) Quantity Part No.
Btu/hr.*
(Mj/hr.)
4,001-6,000
( 1,221-1,830)
12 0.1890 (4.8) M411372 99,562
(105.04)
6,001-8,000
( 1,831-2,440)
14 0.1811 (4.6) M411371 92,324 (97.4)
8,001-10,000
( 2,441-3,050)
16 0.1772 (4.5) M411373 87,321
(92.12)
2,001-4,000
( 610-1,220)
32 0.1142 (2.9) M402444 104,354
(110.09)
4,001-6,000
(1,221-1,830)
33 0.1142 (2.9) M401022 99,027
(104.47)
6,001-8,000
( 1,831-2,440)
35 0.1102 (2.8) M402487 93,838
(97.94)
L.P. Gas
8,001-10,000
( 2,441-3,050)
36 0.1063 (2.7) M411375 87,630
(92.45)
*Btu/hr. derate of 4% per 1,000 feet (305 meters) of altitude.
Table 6 Classic Line Models
Altitude Burner Orifice New Rate
Model Gas feet (meters) No.
inches
( mm) Quantity Part No.
Btu/hr.*
(Mj/hr.)
2,001-4,000
(610-1,220)
31 0.1200 (3.0) M401017 43,200 (46)
4,001-6,000
( 1,221-1,830)
33 0.1130 (2.9) M401022 37,800 (40)
025Series Natural
Gas 50
Hz
6,001-8,000
( 1,831-2,440)
34 0.1110 (2.8)
1
M411512 34,200 (36)
