Gas Requirements
Part No. 70458301ENR7
©
Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT 71
Altitude Burner Orifice New Rate
Model Gas feet (meters) No.
inches
( mm) Quantity Part No.
Btu/hr.*
(Mj/hr.)
2,001-4,000
( 610-1,220)
1/8 0.1250 (3.2) M402489 48,300 (51)
4,001-6,000
( 1,221-1,830)
--- 0.1220 (3.1) 70070903 44,100 (47)
6,001-8,000
( 1,831-2,440)
31 0.1200 (3.0) M401017 39,900 (42)
Natural
Gas 50
Hz
8,001-10,000
( 2441-3,050)
33 0.1130 (2.9) M401022 35,700 (38)
2,001-4,000
( 610-1,220)
--- 0.1299 (3.3) 44253801 50,600 (53)
4,001-6,000
( 1,221-1,830)
1/8 0.1250 (3.2) M402489 46,200 (49)
6,001-8,000
( 1,831-2,440)
--- 0.1220 (3.1) 70070903 41,800 (44)
T30 Series
Natural
Gas 60
Hz
8,001-10,000
(2,441-3,050)
32 0.1160 (2.9)
2
M402444 37,400 (39)
2,001-4,000
( 610-1,220)
29 0.1360 (---) M400997 50,600 (53)
4,001-6,000
( 1,221-1,830)
--- 0.1339 (3.4) 44254001 46,200 (49)
6,001-8,000
( 1,831-2,440)
30 0.1285 (---) M401021 41,800 (44)
Natural
Gas 50
Hz
8,001-10,000
( 2,441-3,050)
--- 0.1220 (3.1) 70070903 37,400 (39)
035Series
Natural
Gas 60
Hz
2,001-4,000
( 610-1,220)
28 0.1405 (3.6)
1
M401014 58,880 (62)
