Electrical Requirements
86
©
Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT Part No. 70458301ENR7
* 3 Phase machines should not have fuses, breakers only.
** Special low Amp blower model, 025 Series only.
N/A = Not Applicable
Table 12
055 Series Gas Models
Serial Plate Amps Recommended
Circuit
Serial Plate
Voltage
Terminal Block
Connections
Required
Nonreversing Reversing Breaker Rating Wire Size AWG
(mm
2
)
120V/60Hz/1ph L1, Neutral, and
ground
9.2 N/A 15A – 1 pole 14 (2.5)
208-240V/60Hz/1ph L1, L2, Neutral,
and ground
6.5 N/A 10A – 2 pole 14 (2.5)
100V/60Hz/1ph L1, Neutral, and
ground
9.8 N/A 15A – 1 pole 14 (2.5)
100V/50Hz/1ph L1, Neutral, and
ground
10 N/A 15A – 1 pole 14 (2.5)
200V/50Hz/1ph L1, Neutral, and
ground
6.2 N/A 15A – 1 pole 14 (2.5)
230-240V/50Hz/1ph L1, Neutral, and
ground
5.5 N/A 10A – 1 pole 14 (2.5)
200-208V/60Hz/3ph L1, L2, L3, and
ground
4.0 4.0 10A* – 3 pole 14 (2.5)
240V/60Hz/3ph L1, L2, L3, and
ground
4.0 4.5 10A* – 3 pole 14 (2.5)
380V/50Hz/3ph L1, L2, L3, and
ground
2.0 2.5 10A* – 3 pole 14 (2.5)
400-415V/50Hz/3ph L1, L2, L3, and
ground
2.0 2.5 10A* – 3 pole 14 (2.5)
