Electrical Requirements
Part No. 70458301ENR7
©
Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT 87
* 3 Phase machines should not have fuses, breakers only.
N/A = Not Applicable
Table 13
T30 Series Gas and Steam Models (Total Machine)
Recommended CircuitSerial Plate Voltage Terminal Block
Connections Required
Serial Plate Amps
Breaker Rating Wire Size AWG (mm
2
)
120V/60Hz/1ph L1, Neutral, and
ground
16.0 20A – 1 pole 12 (4)
208-240V/60Hz/1ph L1, L2, Neutral, and
ground
8.0 10A – 2 pole 14 (2.5)
100V/60Hz/1ph L1, Neutral, and
ground
22.0 30A – 1 pole 10 (6)
200-220V/60Hz/1ph L1, Neutral, and
ground
11.6 15A – 1 pole 14 (2.5)
100V/50Hz/1ph L1, Neutral, and
ground
24.2 35A – 1 pole 8 (10)
200/50Hz/1ph L1, Neutral, and
ground
15.0 20A – 1 pole 12 (4)
230-240V/50Hz/1ph L1, Neutral, and
ground
9.0 15A – 1 pole 14 (2.5)
200-208V/60Hz/3ph L1, L2, L3, and ground 6.4 10A* – 3 pole 14 (2.5)
240V/60Hz/3ph L1, L2, L3, and ground 6.4 10A* – 3 pole 14 (2.5)
200V/50Hz/3ph L1, L2, L3, and ground 5.8 10A* – 3 pole 14 (2.5)
230-240V/50Hz/3ph L1, L2, L3, and ground 7.0 10A* – 3 pole 14 (2.5)
380V/50 or 60Hz/3ph L1, L2, L3, and ground 3.0 10A* – 3 pole 14 (2.5)
