Electrical Requirements
88
©
Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT Part No. 70458301ENR7
400-415V/50Hz/3ph L1, L2, L3, and ground 3.2 10A* – 3 pole 14 (2.5)
440V/60Hz/3ph L1, L2, L3, and ground 3.3 10A* – 3 pole 14 (2.5)
460-480V/60Hz/3ph L1, L2, L3, and ground 3.3 10A* – 3 pole 14 (2.5)
* 3 Phase machines should not have fuses, breakers only.
Table 14
T45 Series Gas Models (Total Machine)
Recommended CircuitSerial Plate Voltage Terminal Block
Connections Required
Serial Plate Amps
Breaker Rating Wire Size AWG (mm
2
)
208-240V/60Hz/1ph L1, L2, Neutral, and
ground
12.0 15A – 2 pole 14 (2.5)
230V/50Hz/1ph L1, Neutral and ground 10.2 15A – 1 pole 14 (2.5)
200V/50Hz or
60Hz/1ph
L1, Neutral and ground 11.2 15A – 1 pole 14 (2.5)
230-240V/50Hz/1ph L1, Neutral and ground 10.8 15A – 1 pole 14 (2.5)
200-208V/60Hz/3ph L1, L2, L3, and ground 9.6 15A* – 3 pole 14 (2.5)
240V/60Hz/3ph L1, L2, L3, and ground 9.6 15A* – 3 pole 14 (2.5)
* 3 Phase machines should not have fuses, breakers only.
Table 15
9 kW Classic Line 025 Series Electric Models
Serial Plate Amps Recommended CircuitSerial Plate
Voltage
Terminal Block
Connections
Required
Nonreversing Reversing Breaker Rating Wire Size AWG
(mm
2
)
