Electrical Requirements
Part No. 70458301ENR7
©
Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT 89
400V/50Hz/3ph L1, L2, L3, and
ground
16 N/A 20A* – 3 pole 12 (4)
* 3 Phase machines should not have fuses, breakers only.
N/A = Not Applicable
Table 16
9 kW Eco Line 025 Series Electric Models
Serial Plate Amps Recommended CircuitSerial Plate
Voltage
Terminal Block
Connections
Required
Nonreversing Reversing Breaker Rating Wire Size AWG
(mm
2
)
380V/50Hz/3ph L1, L2, L3, and
ground
14.8 N/A 20A* – 3 pole 12 (4)
400-415V/50Hz/3ph L1, L2, L3, and
ground
13.7 N/A 20A* – 3 pole 12 (4)
* 3 Phase machines should not have fuses, breakers only.
N/A = Not Applicable
Table 17
12 kW 025 Series Electric Models
Serial Plate Amps Recommended CircuitSerial Plate
Voltage
Terminal Block
Connections
Required
Nonreversing Reversing Breaker Rating Wire Size AWG
(mm
2
)
208V/60Hz/1ph L1, L2, Neutral,
and ground
64 N/A 80A – 2 pole 4 (25)
240V/60Hz/1ph L1, L2, Neutral,
and ground
57 N/A 80A – 2 pole 4 (25)
200V/50Hz/1ph L1, Neutral, and
ground
63 N/A 80A – 1 pole 4 (25)
200V/60Hz/1ph L1, L2 and ground 64 N/A 80A – 2 pole 4 (25)
