32 70291301
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Adjustments
b.
O
pen cover for coin drop. Refer to
Figure 11.
Coin Drops with New-Style Spring
Refer to
Figure 12
.
Figure 12
c. Open cover of coin drop. Refer to Figure 13.
NOTE: Do not overbend the spring by opening
cover too far.
Figure 13
4. Clean the coin path with a soft brush and wipe
exposed surfaces with an alcohol moistened
cloth. Refer to Figure 14 and Figure 15.
DRY2088N
1 Catch
Figure 10
DRY2089N
1 Cover
Figure 11
DRY2088N
DRY2404N
1 Spring
DRY2408N
1 Spring
To Next Page
