Allied Telesis AT-9924SP - Cables for RJ-45 Ethernet LAN Interfaces

30 x900 Series Switch and SwitchBlade
®
x908
C613-03092-00 REV J
Cables
This section describes the following:
■ RS-232 Terminal and Modem Cables
■ Cables for RJ-45 Ethernet LAN Interfaces
■ Cables for Stacking
■ Cable Guidelines
■ Troubleshooting Cables
RS-232 Terminal and Modem Cables
The terminal and modem cables described in this section are:
■ RS-232 RJ-45 to DB9 female terminal cable
■ DCE RS-232 terminal port RJ-45 to DB9 male modem cable
Figures in this section show pin wiring diagrams to connect a standard VT100
compatible terminal or modem to ASYN0.
RJ-45 to DB9
female terminal
cable
Note
This cable supplied as part number C855-84903-00.
Now at version B.
RJ45DB9F_x900
1
2
3
4
5
6
7
8
9 not connected
4
3
6
7
5
2
8
1
RJ-45
(to switch)
DB9 Female
(to terminal)
