Allied Telesis AT-9924SP - Troubleshooting Cables

Hardware Reference 33
C613-03092-00 REV J
Cable Guidelines
The following table lists port, connector, and cable combinations for switches
and expansion modules.
1. Refer to the IEEE Standard 802.3 for additional cable information
Switch / Expansion module Port Type Connector Type Cable Type
1
Max Cable Length
AT-8948
x900-48FE
x900-48FE-N
10BASE-T /
100BASE-TX
RJ-45 CAT5 100 m Max
120 m Max
AT-9924T
AT-9924Ts
x900-12XT/S
x900-24XT
x900-24XT-N
AT-A62
XEM-12 T
10BASE-T /
100BASE-TX /
1000BASE-T
RJ-45 CAT5
CAT5
CAT5E
100 m Max
120 m Max
100 m Max
x900-48FS 100BASE-X Varies with SFP Refer to
documentation with
SFP
Refer to
documentation with
SFP
AT-8948
x900-48FE
x900-48FE-N
x900-48FS
AT-9924T
AT-9924SP
AT-A61
x900-12XT/S
x900-24XS
XEM-12 S
1000BASE-X Varies with SFP Refer to
documentation with
SFP
Refer to
documentation with
SFP
AT-A60
XEM-1 XP
XEM-2XP
10GBASE Refer to
documentation with
XFP
Refer to
documentation with
XFP
XEM-STK
SwitchBlade x908
Stacking
Stacking
PCIe x8
PCIe x16
AT-XEM-STK-CBL0.5
AT-XEM-STK-CBL2.0
AT-HS-STK-CBL1.0
0.5 m
2.0 m
1.0 m
