Network Topologies
The AT-FS716 Series and AT-FS724i switches can be used in a variety of
network topologies, such as a power workgroup or cascade. Both topologies are
described below.
Power Workgroup Topology
A power workgroup topology, shown in Figure 3, allows each end-node to
directly connect to a 10/100Base-TX port on an AT-FS716 switch. This gives
each end-node a dedicated 10 Mbps or 100 Mbps link.
Figure 3 Power Workgroup Topology
Workstations
Workstations
Server
AT-FS716
10 Mbps
100 Mbps
