AT-FS716 Series and AT-FS724i Installation Guide
3
Status LEDs
Table 2 lists the status LEDs for the AT-FS716 Series and AT-FS724i switches.
Table 2 Status LEDs
Power Requirements
Internal Power Supply
The AT-FS716 and AT-FS724i use a universal internal switching power supply
with 100 to 240 V AC, 50/60 Hz, 0.5A input rating. Allied Telesyn ships power
cords with these units to the U.S., Continental Europe, and the U.K. The
switches require input of 100 to 240 V AC. The AT-FS716 and AT-FS716E
switches have a maximum power consumption of 8W. The AT-FS724i switch
has a maximum power consumption of 15W.
External Power Supply
The AT-FS716E uses an external power adapter which is included with the
unit.
LED Color Description
POWER Green Power is applied to the switch.
LINK/ACTIVITY Green
Blinking
OFF
A valid link has been established on the port.
The port is transmitting data.
A link has not been detected on the port.
100M Green
OFF
The port is operating at 100 Mbps.
The port is operating at 10 Mbps.
FDX
(Full-duplex)
Green
OFF
The port is operating in full-duplex mode.
The port is operating in half-duplex mode.
