Cascade Topology
Connecting two similar networking devices together is called ‘cascading’.
Figure 4 illustrates this topology where Port 24 on the AT-FS724i switch is
connected to Port 8 on the AT-FS716 switch. Since Port 24 is wired as auto
MDI/MDI-X, a crossover or straight-through Category 5 or better twisted pair
cable can be used.
Figure 4 Cascade Topology
Workstations
AT-FS724i
Workstations
Server
AT-FS716
100 m (328 ft)
10 Mbps
100 Mbps
