508433-01 Issue 2345 Page 3 of 70
BLOWER DATA: UPFLOW / HORIZONTAL
A97UH2E030B08S PERFORMANCE (Less Filter)
External
Static
Pressure
in. w.c.
Rise Range °F Air Volume / Watts at Various Blower Speeds
1st
Stage
2nd
Stage
High Medium-High Medium Medium-Low Low
cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts
0.10
15-45 30-60
1037 156 964 130 863 101 755 77 742 73
0.20 1001 164 927 137 824 111 689 82 535 55
0.30 968 177 891 147 776 117 634 88 470 59
0.40 937 185 849 157 743 125 596 98 410 66
0.50 896 196 806 167 703 134 544 104 344 72
0.60 865 207 768 173 665 145 502 109 305 79
0.70 835 213 736 184 619 151 459 117 255 84
0.80 787 224 689 193 575 159 412 123 230 88
0.90 743 231 659 199 533 166 365 130 n/a n/a
1.00 664 221 617 207 500 173 n/a n/a n/a n/a
A97UH2E045B12S PERFORMANCE (Less Filter)
External
Static
Pressure
in. w.c.
Rise Range °F Air Volume / Watts at Various Blower Speeds
1st
Stage
2nd
Stage
High Medium-High Medium Medium-Low Low
cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts
0.10
20-50 30-60
1395 348 1246 249 1139 198 911 111 847 96
0.20 1375 358 1206 258 1105 203 876 120 809 103
0.30 1348 367 1184 267 1079 215 839 122 768 109
0.40 1318 380 1160 278 1046 221 798 132 733 115
0.50 1294 386 1125 286 1014 230 755 139 694 124
0.60 1265 398 1097 296 987 239 710 145 652 132
0.70 1216 393 1066 304 957 247 665 156 606 136
0.80 1147 374 1043 314 923 256 624 160 569 145
0.90 1062 350 1010 320 889 267 589 166 532 151
1.00 941 314 917 301 846 271 556 177 486 156
A97UH2E070B12S PERFORMANCE (Less Filter)
External
Static
Pressure
in. w.c.
Rise Range °F Air Volume / Watts at Various Blower Speeds
1st
Stage
2nd
Stage
High Medium-High Medium Medium-Low Low
cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts
0.10
25-55 35-65
1395 333 1242 240 1137 190 912 107 851 94
0.20 1367 346 1214 252 1104 202 872 116 813 103
0.30 1332 362 1182 260 1071 213 832 123 762 110
0.40 1311 372 1153 274 1043 218 775 134 721 117
0.50 1287 382 1119 285 1001 231 735 141 675 125
0.60 1249 394 1087 294 968 241 681 148 625 134
0.70 1199 387 1055 306 934 249 641 156 581 142
0.80 1112 369 1013 316 891 259 596 166 540 149
0.90
1009 337 946 309 856 268 554 172 483 157
1.00 840 294 833 282 793 269 516 182 443 165
