A:ShiftSelectors
(1)–HoldOverrideButton
(2)–Upshift
(3)–ManualSelect
(4)–Downshift
(5)–ModeButton
(6)–DigitalDisplay
(7)–DisplayMode/DiagnosticButton
B:PushButtonSelectors
(B1)–Common
(B2)–Standard
(B3)–Compact
C:LocationofServiceIconOnVerticalandHorizontalDigitalDisplay
(8)–ServiceIcon
(9)–SelectDisplay
(10)–MonitorDisplay
Figure4–1.TypicalAllisonShiftSelectors
NOTE:5thGenerationpushbuttonshiftselectorsarenotforwards
compatiblewith6thGenerationTCMsand6thGenerationpush
buttonshiftselectorsarenotbackwardscompatiblewith5th
GenerationTCMs.
NOTE:Therstnumberdisplayedinthedigitaldisplayisthehighest
forwardrangeavailableandthesecondnumberisrangeattained
inselectedposition.
Visuallyconrmthattherangeselectedwasattained.Ifdisplayis
ashing,shiftisinhibited.
4.1.2.1USINGSTRIPPUSHBUTTONSELECTORTOSELECTRANGE
RefertoFigure4–2.
NOTE:ThestrippushbuttonselectorsdonotincludeaVacuum
FluorescentDisplay(VFD).Theseinstallationsrequiretheinstallation
ofaseparateSAEJ1939-compatibledisplaystoalerttheoperatorof
conditionsmonitoredbytheoptionalprognosticsfeature.
•R–REVERSE:selectsR(Reverse)gear.
•N–NEUTRAL:itisnotnecessarytopressthisbuttonpriortostarting
thevehicle.
•D–DRIVE:selectsthehighestavailableforwardrange.Transmission
shiftstothestartinggearandwillautomaticallyupshiftthroughthe
gears,asoperatingconditionspermit,untilthehighestavailablegear
isattained.
49

Allison Transmission 3000 Series Specifications

General

Type	Automatic Transmission Controller
Control Module	Integrated
Shift Energy Management	Yes
Number of Gears	6
Torque Converter	Yes, with lock-up clutch
Retarder	Optional
PTO Provision	Yes
Input Voltage	12V or 24V
Communication Protocol	SAE J1939
Operating Temperature Range	-40°C to +85°C
