Allison Transmission 3000 Series User Manual

4.2SHIFTSCHEDULESANDAUTOMATICRANGESHIFTS
Eachtransmissionshiftcalibrationincludesmultipleshiftscheduleswhich
areusedtocontroltransmissionshiftsinvariousoperatingconditions.The
shiftschedulesaffectthetimingofshiftsbetweengears.Theactualnumber
offorwardgearsisdeterminedbasedonthetransmissionmodelandthe
selectedrangepositionoftheshiftselector.
Vehicleperformancemaybeaffectedwhenshiftscheduleschange.The
transitionbetweenshiftschedulescanbeinitiatedbyseveraldifferentactions.
ThetransmissioninitiallyattainsrstrangewhenD(Drive)isselected(except
forthoseunitsprogrammedtostartin2(SecondRange).Asvehiclespeed
increases,thetransmissionautomaticallyupshiftsthrougheachrange.Asthe
vehicleorequipmentslowsdown,thetransmissionautomaticallydownshifts
tothecorrectrange.TheSELECTdisplayshowsthehighestrangeavailable
inD(Drive).
NOTE:ThevehicleOEMorbodybuilderisresponsibleforevaluating
thedriveabilityofshiftschedulesintheintendedvehicleandduty
cycle.Foradditionaldetailsregardingtheseshiftschedulesand/or
otheroptionsforprimaryandsecondaryshiftschedules,contacta
qualiedAllisonTransmissionserviceoutletforfurtherinformation.
4.2.1UPSHIFTING.AslongastheTCMcalculatesthatthereisenough
vehiclepowerandvehicleaccelerationavailabletograntandkeepthe
nextupshift,thentherearenootherlimitationsimposedonupshiftinguntil
thevehicleattainsitstoprangedisplayedintheSELECTdisplayonthe
selector.Vehiclepowerandaccelerationcharacteristicsaremonitoredbythe
transmissioncontrolstoattempttoeliminateshiftcycling.Shiftcyclingisan
upshiftfollowedcloselybyadownshift,whichisthenfollowedbyanother
upshift,andsoon.
NOTE:Ifshiftcyclingisnoted,usethealternateshiftscheduleby
pressingtheMODEbutton.Theoperatorcanalsomanuallyselect
thenextlowerrange(usingtheshiftselector)toholdthatlower
rangeuntilconditionsaremettogranttheupshiftpointagainwithout
shiftcycling.
4.2.1.1HOLDSCHEDULEFORUPSHIFTS
Asastandardfeatureofeachshiftcalibration,thetransmissioncontrols
incorporatea"holdupshift"shiftschedule,whichtheoperatormayselectif
thetransmissionisnotoperatinginitshighestrange.Whenthisscheduleis
60

Allison Transmission 3000 Series Specifications

General

Type	Automatic Transmission Controller
Control Module	Integrated
Shift Energy Management	Yes
Number of Gears	6
Torque Converter	Yes, with lock-up clutch
Retarder	Optional
PTO Provision	Yes
Input Voltage	12V or 24V
Communication Protocol	SAE J1939
Operating Temperature Range	-40°C to +85°C
