Allison Transmission 3000 Series User Manual

NOTE:Thetransmissionretarderisconguredaseitheralow,
medium,orhighcapacityretarderbyTCMcalibration.Allison
TransmissionrequireswrittenvehicleOEMapprovalbeforeaservice
outletincreasestheretardercapacityatacustomer'srequest.
Existingvehicledrivelines,differentials,axles,andthecoolingsystem
mustbedesignedfortheadditionalretardertorquegeneratedifa
highercapacityretardercalibrationisinstalled.Thecosttomodify
retardercapacityistheresponsibilityofthecustomer.
TheamountofRetarderModulationRequest(RMR)iscontrolledbythe
operatoranddependsonthetypeofretardercontrolusedinthevehicle.
Varioushand,footandautomaticcontroltechniquesareused.Referto
Table4–7.BeginningwithAllison5thGenerationControls,theTCMalso
activatesorlimitsretarderoperationinresponsetotorquespeedcontrolor
electronicretardercontrolmessagesreceivedonthevehicle’sSAEJ1939
Datalink.ContactyourOEMtounderstandhowtheretardercontrolshave
beenintegratedintoyourvehicle.
ThepresenceofaretardermustbeautodetectedbeginningwithAllison5th
GenerationControls.
NOTE:Theretarderenableswitchisusedtoturntheretarderofffor
slipperyroadconditions.
73

Allison Transmission 3000 Series Specifications

General

Type	Automatic Transmission Controller
Control Module	Integrated
Shift Energy Management	Yes
Number of Gears	6
Torque Converter	Yes, with lock-up clutch
Retarder	Optional
PTO Provision	Yes
Input Voltage	12V or 24V
Communication Protocol	SAE J1939
Operating Temperature Range	-40°C to +85°C
