Phone Guide - 9202
iii. Disabled (Default)
c.
Remote Plug ‘n’ Play – Key used to set up a remote phone. See the System Administrator.
d.
Edit Time Server IP – Option to change the Time Server the phone is logged into.
e.
Edit Boot Server IP – The WAN IP address the server is using for the setup of a remote phone.
f.
Edit Phone IP – Option will appear if DHCP is disabled. Allows the manual entry of the phone’s
IP.
g.
Edit Netmask IP – Option will appear if DHCP is disabled. Allows the manual entry of the
Netmask IP.
h.
Edit Gateway IP – Option will appear if DHCP is disabled. Allows the manual entry of the
Gateway IP.
i.
Phone VLAN Settings – Option will appear if VLAN is enabled.
i. Enter VLAN ID – 2 (Default)
ii. Enter VLAN Priority – 7 (Default)
j.
PC VLAN Settings – Option will appear if VLAN is enabled.
i. Enter VLAN ID – 1 (Default)
ii. Enter VLAN Priority – 0 (Default)
4. Select the EXIT soft key.
5. Select the YES soft key to save any changes OR select NO to cancel changes made.
7.8 Current Status / Info
1. Select the CONFIG soft key.
2. Highlight Current Status/Info.
3. Press the Select button .
4. The following information is listed:
• DHCP Lease Time (if DHCP is enabled)
• SNTP Time Server IP
• Boot Server IP
• Phone IP
• Subnet IP
• Gateway IP
• Boot Configuration success or failure
• MAC Address
• Model Name
• Software Version
300 Main Street • East Rochester, NY 14445 • Toll Free 1-866-ALLWORX • 585-421-3850 • www.allworx.com
© 2008 Allworx. All rights reserved.
Revised: May 28, 2008
Page 21
