HP 5 OPERATOR’S MANUAL
HP 5 COMBINE COMPONENT LIST
REF # ALMACO# DESCRIPTION QTY
1 22041 SPROCKET, IDLER, 15T 1
2 22210 CHAIN, #50 1
3 22345 SPROCKET, 20T, MAIN JACK SHAFT 1
4 22406 SPROCKET, 60T, AUXILIARY JACK SHAFT 1
24039 BUSHING, 1” 1
5 22143 SPROCKET, 20T, AUXILIARY JACK SHAFT 1
6 22278 SPROCKET, 30T, INTERNAL CONVEYOR ROLLER 1
7 22111 SPROCKET, 16T, MAIN JACK SHAFT 1
8 22123 SPROCKET, 48T, STRAWPULLER / SHAKER 1
24032 BUSHING, 1” 1
9 22040 SPROCKET, IDLER, 17T 1
10 22206 CHAIN, #40 1
11 21241 CLUTCH, ELECTRIC 1
195278 PULLEY, CLUTCH 1
12 21107 PULLEY, IDLER 1
13 25251 V-BELT, MAIN DRIVE BELT 1
14 21163 PULLEY, V-BELT, OUTSIDE, JACK SHAFT 1
24083 HUB, 1-1/4” 1
15 21112 PULLEY, V-BELT, INSIDE, JACK SHAFT 1
24010 HUB, 1-1/4” 1
16 25116 V-BELT, JACK SHAFT TO WINNOWING BLOWER 1
17 21101 PULLEY, IDLER 1
18 22005 PULLEY, INSIDE, VARIABLE PITCH WINNOWING BLOWER 1
19 21046 PULLEY, OUTSIDE, WINNOWING BLOWER 1
24005 HUB, 3/4” 1
20 21101 PULLEY, IDLER 1
21 22003 PULLEY, VARIABLE PITCH, CYCLONE BLOWER 1
22 25062 V-BELT, WINNOWING BLOWER TO CYCLONE BLOWER 1
23 21175 SHEAVE HALF, INSIDE, JACK SHAFT 1
21177 SHEAVE HALF, OUTSIDE, JACK SHAFT 1
24 21176 SHEAVE HALF, INSIDE, THRESHING CYLINDER 1
21175 SHEAVE HALF, OUTSIDE, THRESHING CYLINDER 1
25 25215 V-BELT, VARIABLE SPEED, THRESHING CYLINDER 1
26 22141 SPROCKET,16T, STANDARD HEAD 1
27 22019 TORQUE LIMITER 1
22351 SPROCKET, 26T, TORQUE LIMITER 1
28 22349 SPROCKET, 26T, JACK SHAFT, STANDARD HEAD 1
29 22310 SPROCKET,19T, JACK SHAFT, STANDARD HEAD 1
30 22312 SPROCKET, 72T ALMACO MODIFIED 1
31 22313 SPROCKET, 72T 1
32 IDLER, NYLATRON 1
33 22311 SPROCKET, 19T ALMACO MODIFIED 1
34 22205 CHAIN, #35 1
DIAGRAMS H-9
