HP 5 OPERATOR’S MANUAL
35 22324 SPROCKET, 25T 1
36 22019 TORQUE LIMITER 1
22022 SPROCKET, 30T 1
37 22132 SPROCKET, 16T, ALMACO MODIFIED 1
22321 HUB, ALMACO MODIFIED 1
38 22348 SPROCKET, 11T, ALMACO MODIFIED 1
22321 HUB, ALMACO MODIFED 1
39 22347 SPROCKET, 56T, ALMACO MODIFIED 1
22193 HUB, ALMACO MODIFIED 1
40 22019 TORQUE LIMITER 1
22279 SPROCKET, 21T 1
41 195192 SPROCKET, 20T, ALMACO MODIFIED 1
42 22166 SPROCKET, 19T 1
24030 HUB, 1” 1
43 22352 SPROCKET, 29T 1
44 22318 SPROCKET,19T 1
45 21109 IDLER, V-BELT 1
46 25250 V-BELT 2
47 21202 PULLEY, V-BELT 2
24092 HUB, 1-3/8” 1
24007 HUB, 1” 1
48 166530 WOOD IDLER BLOCK 1
A 195152 JACK SHAFT, MAIN 1
20004 BEARING, 1-1/4”, JACK SHAFT MAIN 2
20024 FLANGETTE 4
B 195131 SHAFT, WINNOWING BLOWER 1
40455 BLOWER WHEEL 2
20036 BEARING, WINNOWING BLOWER 2
C 116075 CYCLONE BLOWER 1
20067 BEARING, CYCLONE BLOWER 2
D 116057 SHAKER ARM, WOODEN 4
20003 BEARING, STRAWPULLER/SHAKER 2
20022 FLANGETTE 4
E 195153 JACK SHAFT, AUXILIARY 1
20003 BEARING, 1”, AUXILIARY JACK SHAFT 2
20022 FLANGETTE 4
F 20003 BEARING, 1”, INTERNAL CONVEYOR DRIVEN 2
20103 FLANGETTE 4
F1 20003 BEARING, 1”, INTERNAL CONVEYOR IDLER 2
20022 FLANGETTE 4
G 20111 BEARING, THRESHING CYLINDER, VARIABLE SPD 2
20024 FLANGETTE 4
G1 20082 BEARING, THRUST, VARIABLE SPEED 2
H 20085 BEARING, HEADER PIVOT, STD HEAD 2
20056 BEARING, HEADER BELT LOWER 2
H-10 DIAGRAMS
