Chapter 5: Changing Capture Hoods 47
Figure 19: 1 ft  5 ft (305 mm  1525 mm) hood and frame. The support poles always cross as pairs at the
front and back of the fabric hood. For the 1 ft  5 ft (305 mm  1525 mm), the support poles are inserted into
the inside ferrule locations.
2
1
3
1
2
3
5
5
