Chapter 5 Parameter Introductions
http://www.acdrive-china.com
129
◆Ac drive will not run when terminal RJOG is enabled, or terminal REV is enabled.
5.4 I/O Terminal Ctrl (Group P3)
P3.00 Terminal function mode
Range: 0～1【0】
0: Close valid 1: Open valid
Note:
◆ Close valid: Signal is enabled if the control terminal and COM terminal are
short-circuit;
◆ Open valid: Signal is disabled if the control terminal and COM terminal are
short-circuited. Normally open and normally close are not limited.
P3.01 Multi-function input selection Terminal X1
Range: 0～53【1】
P3.02 Multi-function input selection Terminal X2
Range: 0～53【2】
P3.03 Multi-function input selection Terminal X3
Range: 0～53【37】
P3.04 Multi-function input selection Terminal X4
Range: 0～53【26】
P3.05 Multi-function input selection Terminal X5
Range: 0～53【27】
P3.06 Multi-function input selection Terminal X6
Range: 0～53【28】
P3.07 Multi-function input selection Terminal X7
Range: 0～57【0】
P3.08 Multi-function input selection Terminal X8
Range: 0～57【0】
Note:
◆For models which power is equal or below 3004GB, function code P3.06 ~ P3.08
can not be modified; but P3.04, P3.05 (X4, X5 terminal) will function as P3.07,
P3.08 (X7, X8 terminal) correspondingly, the setting range is from 0 to 57;
◆Control terminals X1~X8 are multi-function terminals. They can be defined by preset
P3.01~P3.08, which are allowed function redefined. The redefined function terminal,
if one of them is valid, the function is effective. For the details of settings and
functions of P3.01~P3.08, refer to Table 5-3-1.
Table 5-3-1 Multifunction input selection
Setting Function Setting Function
0 NULL: No defined 1 FWD: Running Forward
2 REV: Running Reverse 3 RUN
4 F/R: Running direction 5 HLD: self-hold selection
