Chapter 5 Parameter Introductions
http://www.acdrive-china.com
157
Note:
◆Record of PLC steps (P5.19) records the steps that the PLC currently operating at.
◆Operating time of this step (P5.20) records the operating time of the step that the PLC
currently operating at.
◆If P5.18 is set to 1, records of PLC steps (P5.19) and operating time of this step (P5.20)
will be cleared , then the value of P5.18 will recovery to 0.
Tips:
You can start, pause, and reset of PLC operating by setting external terminal function,
which is defined in Group 3.
5.7 Wobble Frequency Operating (Group P6)
P6.00 Wobble frequency operation restart mode
Range: 0,1【0】
0: Restart at the freq. and direction before stop, as shown in Fig. 5-6-2.
1: Restart, as shown in Fig. 5-6-3
P6.01 Save wobble frequency operating parameters
Range: 0,1【0】
0: not save 1: save
Note:
◆Not save: The ac drive does not save the wobble frequency operating parameters when
power is off and restart when power is on.
◆Save: The ac drive will save the wobble-frequency operation parameters such as the
operating frequency, and operating direction (UP/DOWN) when power is off. The ac
drive will restart as the mode defined by P6.00 when power is on.
P6.02 Preset of wobble frequency
Range:
The ac drive model of no more than 4kW:
0.00～650.0Hz【0.00Hz】
The ac drive model of no less than 5.5kW:
0.00～400.0Hz【0.00Hz】
P6.03 Holding time before wobble
frequency operating
Range: 0.0～3600s【0.0s】
P6.04 Wobble frequency amplitude
Range: (0.0～50%) of P0.00 【0.0%】
P6.05 Skip frequency
Range: (0.0～50%) of P6.04 【0.0%】
P6.06 Skip Time
Range: 5～50ms【5ms】
P6.07 Wobble frequency operating
cycle
Range:0.1～999.9s 【10.0s】
P6.08 Wobble ratio
Range: 0.1～10.0【1.0】
Note:
