Chapter 5 Parameter Introductions
http://www.acdrive-china.com
156
P5.04 Operating Timing T1
Range: 0.0～3600【10.0】
P5.05 Operating Timing T2
Range: 0.0～3600【10.0】
P5.06 Operating Timing T3
Range: 0.0～3600【10.0】
P5.07 Operating Timing T4
Range: 0.0～3600【10.0】
P5.08 Operating Timing T5
Range: 0.0～3600【10.0】
P5.09 Operating Timing T6
Range: 0.0～3600【10.0】
P5.10 Operating Timing T7
Range: 0.0～3600【10.0】
Note:
◆Configure the operating time of each PLC operating step. The range is 0.00～3600s
(The time unit can be select by P5.03. The default time unit is second). If the operating
time of the step is set to 0, the ac drive will skip the step and run at the next step,
P5.11 Step T1 program operating setting
Range: 1 F～4 r【1F】
P5.12 Step T2 program operating setting
Range: 1 F～4 r【1F】
P5.13 Step T3 program operating setting
Range: 1 F～4 r【1F】
P5.14 Step T4 program operating setting
Range: 1 F～4 r【1F】
P5.15 Step T5 program operating setting
Range: 1 F～4 r【1F】
P5.16 Step T6 program operating setting
Range: 1 F～4 r【1F】
P5.17 Step T7 program operating setting
Range: 1 F～4 r【1F】
Note:
◆P5.11~P5.17 are used to set the direction and Acc/Dec time of each PLC operating
step. Total 8 kinds of combinations, which is shown in Table 5-5-1, could be selected.
Table 5-5-1 Settings of PLC stage
Symbol Acc/Dec time Direction
1F F: Forward
1r
Acc/Dec time 1 P0.21, P0.22
r: Reverse
2F F: Forward
2r
Acc/Dec time 2 P2.18, P2.19
r: Reverse
3F F: Forward
3r
Acc/Dec time 3 P2.20, P2.21
r: Reverse
4F F: Forward
4r
Acc/Dec time 4 P2.22, P2.23
r: Reverse
P5.18 PLC record clear
Range: 0,1【0】
P5.19 Record of PLC steps
Range: 0～7【0】
P5.20 Operating time of this step
Range: 0.0～3600【0.0】
