Chapter 3 Operation
http://www.acdrive-china.com
52
●The ac drive parameters are protected. If function parameter value PF.01=1 or 2, the
parameters are forbidden to be changed. This parameter protection function is to avoid
operation mistake. To change the protection parameters, change value of function code
PF.01 to zero, then all the parameters can be changed.
3.2 Run command mode select
The run command modes determine the methods of the ac drive running and stop. The ac
drive has three run command modes:
●Run command from the keyboard: press the key
RUN
,
STOP
RESET
, to control the ac
drive.
●Run command from the control circuit terminals: by using the terminal defined as
FWD,REV,COM（2-wire control mode）: FWD, REV, Xi（ 3-wire control mode ）
to control the ac drive.
●Run command from serial communication: Use a PC or PLC to control the ac drive to
run or stop.
Change P0.04 to select serial communication mode. The default setting is Keyboard
control mode （The default value P0.04 is 0）, If terminal control mode is needed,
please change the value to 1 or 2. If we want to keep the “STOP/RESET” key
STOP
RESET
active in terminal control mode, we must set the value to 2.
If we need to control the ac drive by PC or PLC serial communication, we should set
P0.04 to 3 or 4.
If the indicator REMOTE is off, it tells that the ac drive is controlled by the keyboard .If
the indicator REMOTE is on, it tells that the ac drive is controlled by the terminals. In
addition, if the indicator is flickering, it tells the ac drive is controlled by serial
communication.
3.3 Trial Operation
3.3.1 Operation mode of ac drive
This series of ac drive have five operation modes: JOG operation, PID closed loop
operation, Wobble frequency operation, PLC programmed operation and common
operation.
●JOG operation: If the ac drive received a jog operation command （for example,
press
JOG
key） at a stop state, the ac drive will jog running at the jog frequency
reference set by function code P2.00～P2.02.
