Chapter 1 Purchase Inspection
1.1 Unpacking Inspection
All ac drives have passed the strict tests before delivery. After unpacking, please check if
the product was damaged by careless transport, the product specification, model is
complied with the order, and if it has a quality check passed mark. If there is any
problems, please contact the supplier.
1.2 Naming Rule
The naming rule of the product is as following:
Additional description
B ：
W
i
t
h
b
r
a
k
e
;
ALPHA6000 - 3 7R5 G B
Series Code
0
7
5
:
7
5
K
W
7
R
5
:
7
.
5
K
W
R
7
5
:
0
.
7
5
K
W
Motor Power
G ：
G
e
n
e
r
a
l
Application
P ： S
q
u
a
r
e
t
o
r
q
u
e
l
o
a
d
Rated Voltage
S
2
:
s
i
n
g
l
e
p
h
a
s
e
2
2
0
V
2
：
t
h
r
e
e
p
h
a
s
e
s
2
2
0
V
3
： t
h
r
e
e
p
h
a
s
e
s
3
8
0
V
Attention: If the user has special needs, please specify the technology requirement
in the order.
1.3 Nameplate of Ac drive
On the right side of the bottom plate of ac drive, there is a nameplate, which marks the
model and rated values of ac drive. See the following figure:
Inverter types
Motor output power、rated current and frequency
Barcode information
Rated input voltage、current and frequency
Nameplate of Inverter
