Chapter 5 Parameter Introductions
http://www.acdrive-china.com
138
42～44: Terminal PLC Control
◆Start PLC operation: If the function is valid, frequency setting 1 will be selected as
PLC operation. Wobble frequency operation and PID operation are similar.
◆Pausing PLC operation: Timing paused.
If the setting value is 43 and the terminal function is valid, the PLC operation will be
paused and the ac drive runs at zero-speed. If the pausing instruction is removed, the
ac drive will continue the PLC operation from the pause point. If press
“STOP/RESET ” while the Terminal PLC Control is valid and the ac drive is in PLC
running state, The PLC operation counter will be cleared. And start according to start
mode next time. If ac drive is not working in PLC operating mode, the pausing PLC
operation function will be invalid.
◆Reset PLC stop status:
In stop state of PLC operation, the memorized PLC operating information such as the
PLC operating steps, operating time, etc. will be cleared when this terminal is enabled.
45～46: Terminal wobble frequency operation
◆Starts wobble frequency operation: If wobble frequency operation is enabled,
frequency setting 1 will be selected as wobble frequency operation.
◆Reset the wobble frequency operating status: In stop state of wobble frequency
operation, the valid terminal can clear the wobble frequency operating information
memorized in stop.
47: Terminal PID operation
◆Start PID operation: If PID operation terminal is enabled, frequency setting 1 will be
selected as PID close-loop operation.
49,53: Timing drive input
◆If the 49 terminal is valid, start the timing, else zero-clear.
◆If the timing arrives at preset setting of P3.25, stop timing. As shown in Fig.5-3-7:
◆When the 53 terminal is valid, the unit of P3.25(preset of timing arriving) will be
minutes, or it will be second.
