Chapter 5 Parameter Introductions
http://www.acdrive-china.com
176
indicator “m/s” (combination of unit” A” and’ V”) will be lit up. If it is set to 0, line
speed will not be displayed.
◆If PC.08 is set to 1, reference line speed will be displayed in monitoring state, and the
unit indicator “m/s” (combination of unit “A” and “V”) will be lit up. The reference
line speed cannot be adjusted online.
PC.09 Output power (kW)
Range: 0,1【0】
0: No display 1: Display
Note:
◆If PC.09 is set to 1, output power will be displayed with unit “kW” in monitoring state,
and all unit indicators will be off. If it is set to 0, output power will not be displayed.
PC.10 Output torque (％) Range: 0,1【0】
0: No display 1: Display
Note:
◆If PC.10 is set to 1, output torque will be displayed with unit “%” in monitoring state.
If PC.10 is set to 0, output torque will not be displayed.
PC.11 Output voltage (V)
Range: 0,1【0】
PC.12 Bus voltage (V)
Range: 0,1【0】
0: No display 1: Display
Note:
◆If PC.11 is set to 1, output voltage will be displayed in monitoring state, and the unit
indicator “V” will be lit up. If it is set to 0, output voltage will not be displayed.
◆If PC.12 is set to 1, bus voltage will be displayed in monitoring state, and the unit
indicator “V” will be lit up. If it is set to 0, bus voltage will not be displayed.
PC.13 AI1（V） Range: 0,1【0】
PC.14 AI2（V） Range: 0,1【0】
0: No display 1: Display
Note:
◆If PC.13 is set to 1, analog input voltage AI1 will be displayed in monitoring state,
and the unit indicator “V” will be lit up . If it is set to 0, analog input voltage AI1 will
not be displayed.
◆If PC.14 is set to 1, analog input voltage AI2 will be displayed in monitoring state, and
the unit indicator “V” will be lit up. If it is set to 0, analog input voltage AI2 will not be
displayed.
PC.15 Analog PID feedback (no unit)
Range: 0,1【0】
PC.16 Analog PID feed (no unit)
Range: 0,1【0】
0: No display 1: Display
