Alpha ALPHA6000 Series - Page 23

Chapter 2 Installation and Wiring
http://www.acdrive-china.com
23
Category Terminal Name Functions Specifications
24V
+24V
power
supply
Provide ＋24V
power supply for
external equipment.
(The reference ground
is COM)
Max output current
is 200 mA
PLC
Common
terminal of
multi-
function
input
terminal
Common terminal of
multi-function input
Be shorted to 24 V
before delivery
PLC is internal
isolated with 24 V.
GND
Reference
ground of
+10V
power
supply
Reference ground of
analog signal and＋
10V power supply
Internal isolated
with COM,
Common terminal of
+10V,AI1,AI2,AO1(
or AO1,AO2)
COM
Common
terminal of
+24V
power
supply
Be used in
conjunction with
other terminals.
COM is internal
isolated with GND.
Power
supply
CME
Common
terminal of
Y1,Y2(onl
y
35R5GB/3
7R5PB～
3500G)
Common terminal of
multi-function Y1
and Y2 output
(Be shorted to COM
before delivery)
Be shorted to COM
before delivery
CME is internal
isolated with
COM,GND
