P4: Analog and Pulse Function
Function
code
Function
Name
LCD
Display
Range of settings
Default Change
MODBUS
Address
P4.00
Analog
Nonlinea
r
Selection
Analog
Nonlinear
Selection
0:None 1:AI1
2:AI2 3: Pulse
0
× 0500
P4.01
Min
analog
value
Input 1
(AI1
Terminal
)
Min analog
value 1
0.00～P4.03
0.10V
○ 0501
P4.02
Physical
value 1
correspo
nding to
Min
analog
value
Input
Physical
value 1
correspond
ing to Min
0.0～100.0%
0.0%
○ 0502
P4.03
Max
analog
value
Input 1
(AI1)
Max
analog
value1
P4.01～10.00V
10.00V
○ 0503
P4.04
Physical
value 1
correspo
nding to
Max
analog
value
Input
physical
value 1
correspond
ing to Max
0.0～100.0%
100.0%
○ 0504
P4.05
Analog
input
filter
time
constant
1 (AI1
Terminal
)
Analog
input filter
1
0.01～50.00s
0.05s
○ 0505
