Chapter 4 Parameter Index
http://www.acdrive-china.com
87
Function
code
Function
Name
LCD
Display
Range of settings
Default Change
MODBUS
Address
P4.20
AO1
output
range
selection
AO1
output
range
selection
0: 0~10V/0~20mA
1: 2~10V/4~20mA
0
○ 0514
Reserved
(3004GB
or below)
Reserved Reserved 0
-
P4.21
AO2
output
range
selection
(35R5G
B/37R5P
B and
over)
AO2
output
range
selection
0: 0~10V/0~20mA
1: 2~10V/4~20mA
0
○
0515
P4.22
Gain of
AO1
Gain of
AO1
1~200% 100%
○ 0516
Reserved
(3004GB
or below)
Reserved Reserved 0
-
P4.23
Gain of
AO2
(35R5G
B/37R5P
B and
over)
Gain of
AO2
1~200% 100%
○
0517
P4.24
Max
output
frequenc
y of DO
Max output
frequency
of DO
Min Pulse value
output of
DO~50.00kHz
10.00kHz
○ 0518
P4.25
Min
output
frequenc
y of DO
Min output
frequency
of DO
0.00~ Max Pulse
value Output of DO
0.00kHz
○ 0519
