Alpha ALPHA6000 Series - P7: PID Control

Chapter 4 Parameter Index
http://www.acdrive-china.com
91
Function
code
Function
Name
LCD
Display
Range of settings
Default Change
MODBUS
Address
P6.03
Holding
time
before
wobble
frequency
operating
Holding
time of
Preset
wobble
frequency
0.0~3600s 0.0s
○ 0703
P6.04
Wobble
frequency
amplitude
Wobble
frequency
amplitude
0.0~50.0%
(Related to P0.00)
0.0%
○ 0704
P6.05
Skip
frequency
Jitter
frequency
0.0~50.0%
(Related to P6.04)
0.0%
○ 0705
P6.06
Skip Time Jitter Time 5~50ms 5ms
○ 0706
P6.07
Wobble
frequency
operating
cycle
Wobble
frequency
operating
cycle
0.1~999.9s 10.0s
○ 0707
P6.08
Wobble
ratio
Wobble
ratio
0.1~10.0 1.0
○ 0708
P6.09
Random
wobble
selection
Random
wobble
selection
0: Random invalid
1: Random valid
0
○ 0709
P6.10
MAX ratio
of random
Wobble
MAX ratio
of random
wobble
0.1~10.0 10.0
○ 070A
P6.11
MIN ratio
of
random
Wobble
MIN ratio
of random
wobble
0.1~10.0 0.1
○ 070B
P7: PID Control
Function
code
Function
Name
LCD
Display
Range of settings
Default Change
MODBUS
Address
P7.00
PID feed
selection
PID feed
selection
0: PID digital
input
1: AI1 terminal
2: AI2 terminal
3: Pulse
frequency
4: Serial
communication
1
× 0800
