Alpha ALPHA6000 Series - Pb: MODBUS Communication

Chapter 4 Parameter Index
http://www.acdrive-china.com
97
Function
code
Function
Name
LCD
Display
Range of
settings
Default Change
MODBUS
Address
PA.05
Leakage
inductance
%X
Leakage
inductance
%X
0.00%～50.00%
This
value
depends
on the ac
drive
model.
○ 0B05
PA.06
Resistance
of rotor
%R2
Resistance
of rotor
%R2
0.00%～50.00%
This
value
depends
on the ac
drive
model.
○ 0B06
PA.07
Mutual
inductance
Xm
Mutual
inductance
Xm
0.0%～200.0%
This
value
depends
on the ac
drive
model.
○ 0B07
PA.08
Rated
Speed
Rated
Speed
0～24000 rpm
This
value
depends
on the ac
drive
model.
○ 0B08
PA.09
Reserved Reserved Reserved 0
- 0B09
Pb
: MODBUS Communication
Function
code
Function
Name
LCD Display
Range of
settings
Default Change
MODBUS
Address
Pb.00
MODBUS
Baud rate
selection
Baud rate
selection
0: 12001: 2400
2: 48003: 9600
4: 19200
5: 38400
3
× 0C00
Pb.01
MODBUS
slave
address
MODBUS
slave address
1～31
1
× 0C01
Pb.02
MODBUS
parity
selection
Parity bit
selection
0: Even parity
1: Odd parity
2: No parity
0
× 0C02
